Limpet Coil Vessel

Reaction Vessel are one of the most important equipments of any chemical, food, drugs, dyes and allied industries.

There are various types of reaction vessel viz jacketed, Limpet coil in Body flange or Welded Types, Top open type, Top dish type etc.

We manufacture Reaction Vessel with capacity ranging from 100 liters to 20,000 liters in Material of Construction Stainless Steel & Mild Steel depanding on the requirement of the Material to be processed.

OUTER LIMPET COIL

Limpet coil can be made up of mild steel or stainless steel single end single start as well as double and double start as per the application of the user.

S.S. Limpet Coil

Nozzle Orientation

M.S. Limpet Coil

Lenton Assembly

Lenton Assembly contains Bearing Housing with TOP Tapered Roller Bearing for High Accuracy and resistance to impact load & vibratory load and Ball Bearing at the bottom for smooth rotation. Stuffing Box is provided with Jacket for Cooling arrangement to give long life to Gland rope. Gland pusher is provided with Gunmetal Bush Bearing thus ensuring Minimised Friction giving longer life to the Gunmetal Bearing. Bearing Housing and Lenton Assembly are steel Fabricated made from M.S. Plates of suitable strength.

Finish

All weld joints will be finished from inside and outside, S S. Parts is cleaned from inside and outside. Two coates of primer/ redoxide will be given on M.S. parts from outside.

Testing

Equipments and limpet coils are tested Hydraulically as per design Pressure.

Service

After sales servicing is provide by our fully trained and competant engineers.

Limpet Welding

Limpet welding work performed by using high gradefiller rods depending on material of construction of the limpet coil to withstand design pressure.

Mixing With Blades

Mixing With Baffle

Mixing Without Baffle

Types of Blade and Agitator can be used in Reaction Vessels

Double Anchor

Single Anchor

Flat Blade Turbine

Curved Blade Turbine

Gate

Marine Propeller

Paddle

Drive System is specially Designed for Maintenance & Trouble Free Performance.
